| Type | Module | Powerwall |
| Model | LFP48V50AH | LFP48V100AH | LFP48V150AH | LFP48V200AH |
| Battery Capacity [Ah] | 50Ah | 100Ah | 150Ah | 200Ah |
| Nominal Battery Energy [kwh] | 2.4 | 4.8 | 7.2 | 9.6 |
| Max Discharge Current [A] | 50 | 100 | 150 | 200 |
| Net Weight | 35 | 68 | 95 | 108 |
| Dimension [H*W*D, mm] | 442*480*88 | 680*495*185 | 680*495*185 | 680*495*185 |
| Operating Temperature Range | -20 ~ 50 [℃ ]
|
| Life Cycles | >6000 |
| Nominal Voltage [V] | 51.2/48Vdc |
| Communication | CAN/RS485/DRY CONTACT |
| Certificate & Safety Standard | TUV / CE / EN62619 / IEC62040 / UN38.3
|
| Warranty | 1 Years |
| Alarms | Battery Operation/Out of Battery/System fault |
| Pros | Applied in off-grid and hybrid system, Compact Design, Modular Expansion |
| Monitoring & Protection | With BMS protection in each Module, and breaker embedded in the system |
